KEY FEATURES |
|
|
– HD: 1920 * 1080 is higher than the ordinary monitor resolution – Boot on the lower left screen automatically detect the resolution of the input signal is high or low, resolution with data – Clear: exquisite realistic, true color, showing off is my true colors – Bright: quality promotion, to be better – Use industrial screen, high brightness, high contrast – Standard regulated power supply with high precision, for industrial – Equipment design, support x 365 day uninterrupted work 24 hours a day – Using 10 bit figure like chip processing technology, high pixel progressive scan, image quality and exquisite realistic – Support intelligent 3 d noise reduction, to eliminate the ghosting, dynamic brightness, contrast color optimization techniques – Used the world’s leading liquid crystal drive scheme, a precise reduction front-end signal, strong sense of reality – LCD has a small volume, low energy consumption, zero radiation, image stabilization, no influence on the eyes, natural health – 5ms speed response, to avoid the image phenomenon of trailing in the high-speed running. |
|
|
Display |
|
|
Model |
LED24 |
|
Panel size |
24 inch |
|
Resolution |
1920*1080(compitable3840*2160/30HZ) |
|
Display ratio |
16:9 |
|
Brightness |
300cd/㎡(Central point ,typical value) |
|
Contrast |
3000:1 |
|
Visual angle |
89/89/89/89 (Typ.)(CR≥10) |
|
Response time |
5ms(Gray To Gray) |
|
Depth of color |
16.7M |
|
Function attribute |
|
|
Control mode |
Panel |
|
Interface |
|
|
Input power |
12V/4A |
|
Input interface |
HDMI*1、 VGA*1 、USB*1、 Audio output*1 |
|
Power dissipation |
|
|
Total consumption |
24W |
|
Construction |
|
|
Color |
black |
|
Material |
Frame retardant plastic |
|
Overall dimension |
542*320*44mm (excluding foot height 80mm) |
|
Packing Size |
600*110*400mm |
|
Mounting method |
Base wall mounted(100mm*100mm) |
|
Gross weight/Net weight |
2.8kg/3.7kg |
|
Out packing size |
610*580*420mm 5pcs/ctn |
|
Out packing weight |
19.5kg |
|
Working environment |
|
|
Working environment temperature |
Suitable temperature 20℃ |
|
Working environment humidity |
10%-90%RH |
