KEY FEATURES |
|
|
– Using original industrial grade IPS (DID) LCD splicing panel. – Adopt direct down LED backlight technology and shimity of screen brightness. With 1920×1080/3840×2160 resolution, it can restore ultra-high resolution original image display by splicing. – Adopt high heat dissipation body design, support 7×24 hours continuous work, long service life. – Adopt module unit assembly method, support embedded, wall-mounted, hanging and other installation methods.ne out film filter, which can ensure the high unifor. |
|
|
Product Specifications |
|
|
Product Line |
LED Splicing Screen |
|
Splicing thickness |
1.7 MM |
|
Screen size |
55 inch |
|
Appearance color |
Black |
|
Input/output interface |
|
|
USB input |
1 x USB2.0, Max 480Mbps |
|
Audio speaker output |
None |
|
Other |
Equipped with an image engine gas pedal (magic wand) to achieve HDMI ultra-clear resolution 4000X2250 display |
|
Signal Input |
– Support 1 channel HDMI input, support version 1.4, maximum support 3840X2160 input – Support 1 channel DVI signal signal input, the maximum support 1920X1080 input. – Support RJ45 input and output, access to infrared receiver head and RS232 for device control and debugging. – Support image 180-degree flip, (left and right mirror, up and down mirror, need to customize) |
|
Electrical performance of the whole machine |
|
|
Power input |
55 inches |
|
Input |
AC220V 50/60Hz |
|
Power consumption of the whole machine |
55 inches: ≤200w |
|
Speaker power |
No speakers |
|
Main Hardware |
|
|
Size Model |
55 inches |
|
Memory |
All hardware architecture, no memory, no storage |
|
Built-in memory |
Not supported |
|
Memory Expansion |
Not supported |
|
Wi-Fi |
Not supported |
|
Operating System |
All hardware architecture, no CPU and no OS |
|
Display performance parameters |
|
|
Product Model |
PV-554k-W1.7 |
|
Backlight Type |
LED backlighting |
|
Display size(mm) |
1209.6 (H) x 680.4 (V) |
|
Physical resolution rate |
2K (1920 x 1080) |
|
Peak brightness of the whole machine |
500cd/㎡±30 |
|
Dynamic Contrast Ratio |
4000: 1 |
|
Visual View |
89/89/89/89 |
|
Screen Ratio |
16:9 |
|
Display color |
16.7M (10-bit) |
|
Structure size (unit: mm) |
|
|
Overall size of the machine (Length× Height× Thickness) |
1211.84 (H) x 682.64(V) x 70.05(D) |
|
Net weight of bare machine (KG) |
25.3KG |
|
Gross weight of the whole machine (KG) |
50.9G (two-pack) |
