KEY FEACTURE |
||
|
·Metal Housing ·Up to 2592×1944@20fps ·S+265/H.265/H.264 ·Min. illumination Color: 0.002Lux@F1.6 ·120dB WDR ·Smart IR, IR Range: 50m |
·Support tripwire and perimeter ·Built-in Mic, support max 512G Micro SD Card ·Operating Conditions -40℃~65℃, 0~95% RH ·DC12V ·POE, IP67 |
|
|
Camera |
||
|
Image Sensor |
1/2.8″CMOS |
|
|
Min. Illumination |
Color:0.002Lux@(F1.6,AGC ON),B/W:0Lux with IR |
|
|
Shutter Time |
1s-1/100000s |
|
|
Day & Night |
IR-cut filter with auto switch (ICR) |
|
|
WDR |
120dB |
|
|
S/N |
>42dB |
|
|
Angle Adjustment |
0-360°;0-90°;0-360° |
|
|
Lens |
||
|
Lens Type |
Fixed |
|
|
Focal Length |
2.8mm |
|
|
Lens Mount |
M12 |
|
|
Aperture Range |
F1.6,Fixed |
|
|
Field of View |
94.7°(H);71.2°(V);118.5°(D) |
|
|
DORI Distance |
Detect:56.0m Observe:22.2m Recognize:11.2m Identify:5.6m |
|
|
Illuminator |
||
|
IR LEDs |
2 |
|
|
IR Distance |
50m |
|
|
Wavelength |
850nm |
|
|
White LEDs |
N/A |
|
|
Whitelight Distance |
N/A |
|
|
Compression Standard |
||
|
Video Compression |
S+265/H.265/H.264B/H.264M/H.264H |
|
|
Video Bit Rate |
32k-6Mbps |
|
|
Audio Compression |
G.711A/G.711U/ADPCM_D |
|
|
Audio Sampling Rate |
8kHz/32kHz/48kHz |
|
|
Image |
||
|
Max. Resolution |
2592×1944@20fps |
|
|
Main Stream |
PAL:20fps(2592×1944),25fps(2592×1520,2560×1440,2304×1296,1920×1080,1280×720) |
|
|
Sub Stream |
PAL:25fps(704×576,704×288,640×360,352×288) |
|
|
Third Stream |
N/A |
|
|
BLC |
Yes |
|
|
HLC |
Yes |
|
|
AGC |
Yes |
|
|
3D DNR |
Yes |
|
|
White Balance |
Auto/Semi-auto/Manual/Sunny/Natural light/Warm light/Sodium lamp/Incandescent lamp/Locked white balance |
|
|
ROI |
8 regions |
|
|
Corridor mode |
N/A |
|
|
EIS |
N/A |
|
|
OSD |
1region;16*16/32*32/48*48/64*64 |
|
|
Picture Overlay |
N/A |
|
|
Privacy Mask |
4 regions |
|
|
Defog |
Yes |
|
|
Feature |
||
|
Alarm Trigger |
Motion Detection; Mask Alarm; Disk Full; Disk R/W Error; IP Address Conflict |
|
|
Linkage Method |
trigger recording; trigger capture; notify surveillance center |
|
|
Video Analytics |
Tripwire; Perimeter |
|
|
Rules of behavior analyse in 1 scene |
2 |
|
|
Early Warning (EW) |
N/A |
|
|
Auto-Tracking |
N/A |
|
|
Face Mode |
N/A |
|
|
Face Detection Performance |
N/A |
|
|
Network |
||
|
ANR |
ANR |
|
|
Protocols |
HTTP; HTTPS; TCP/IP; UDP; UPnP; ICMP; DHCP; DNS; DDNS; Easy DDNS; NTP; QoS; IPv4; SSH; Unicast; RTSP; FTP |
|
|
System Compatibility |
P2P(Mutually exclusive with Profile G); Onvif Profile S/T/G;CGI;MIL STONE |
|
|
Remote Connection |
≤2 |
|
|
Client |
Easy7 Smart Client |
|
|
Mobile Client |
Easy Live Plus |
|
|
Web |
IE10+;Firefox52+;Edge89+;Safari11+;Chrome57+ |
|
|
Interface |
||
|
Communication Interface |
1 RJ45 10M/ 100M self-adaptive Ethernet port |
|
|
Audio I/O |
N/A |
|
|
Alarm I/O |
N/A |
|
|
Built-In Mic |
Yes |
|
|
Built-In Speaker |
N/A |
|
|
Reset Button |
Yes |
|
|
On-board storage |
Built-in Micro SD card slot, up to 512 GB |
|
|
Additional interfaces |
N/A |
|
|
General |
||
|
Operating Temperature |
-40℃-65℃ |
|
|
Operating Humidity |
0-95% |
|
|
Storage Temperature |
-40℃-65℃ |
|
|
Storage Humidity |
0-95%(non-condensing) |
|
|
Power Supply |
DC12V±25%, MAX 6W; POE 802.3af, MAX 7W |
|
|
Protection |
Surge protection 2000V; Lightning proof 6000V; IP67 |
|
|
Boundary Dimensions |
160(L)73(W)73(H)mm |
|
|
Package Dimensions |
215(L)95(W)120(H)mm |
|
|
Gross Weight |
0.65kg |
|
|
Net Weight |
0.52kg |
|
