Key Features |
|
|
|
·Metal Housing ·Motorized Lens 2.7-13.5mm ·Up to 3840×2160@30fps ·S+265/H.265/H.264/M-JPEG ·Min. illumination Color: 0.002Lux@F1.6 ·Smart IR, IR Range: 80m |
·Built-in Mic, support max 512G Micro SD Card ·Support Human/Vehicle Classification ·Audio I/O 1/1, alarm I/O 2/1 ·Plugin Free ·Operating Conditions -35℃~65℃, 0~95% RH ·POE, IP67 |
|
|
Camera |
||
|
Image Sensor |
1/2.8″CMOS |
|
|
Min. Illumination |
Color:0.002Lux@(F1.6,AGC ON),B/W:0Lux with IR |
|
|
Shutter Time |
1s-1/100000s |
|
|
Day & Night |
IR-cut filter with auto switch (ICR) |
|
|
WDR |
120dB |
|
|
S/N |
>42dB |
|
|
Angle Adjustment |
0-360°;0-90°;0-360° |
|
|
Lens |
||
|
Lens Type |
Motorized |
|
|
Focal Length |
2.7-13.5mm |
|
|
Lens Mount |
Φ14 |
|
|
Aperture Range |
F1.6,Fixed |
|
|
Field of View |
106.7°-31.5°(H);57.3°-17.8°(V);121.1°-36.2°(D) |
|
|
DORI Distance |
Detect:77m-331m Observe:30.55m-131m Recognize:15.5m-66m Identify:7.5m-33m |
|
|
Illuminator |
||
|
IR LEDs |
4 |
|
|
IR Distance |
80m |
|
|
Wavelength |
850nm |
|
|
White LEDs |
N/A |
|
|
Whitelight Distance |
N/A |
|
|
Compression Standard |
||
|
Video Compression |
S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG |
|
|
Video Bit Rate |
32k-16Mbps |
|
|
Audio Compression |
G.711A/G.711U/ADPCM_D/AAC_LC |
|
|
Audio Sampling Rate |
8kHz/32kHz/48kHz |
|
|
Image |
||
|
Max. Resolution |
3840×2160@30fps |
|
|
Main Stream |
PAL:25fps(3840×2160,3072×2048,2560×1440,2304×1296,1920×1080,1280×720) NTSC:30fps(3840×2160,3072×2048,2560×1440,2304×1296,1920×1080,1280×720) |
|
|
Sub Stream |
PAL:25fps(704×576,704×288,352×288,640×360) NTSC:30fps(704×480,704×240,352×240,640×360) |
|
|
Third Stream |
PAL:25fps(704×576,704×288,352×288,640×480) NTSC:30fps(704×480,704×240,352×240,640×360) |
|
|
BLC |
Yes |
|
|
HLC |
Yes |
|
|
AGC |
Yes |
|
|
3D DNR |
Yes |
|
|
White Balance |
Auto/Semi-auto/Manual/Sunny/Natural light/Warm light/Sodium lamp/Incandescent lamp/Locked white balance |
|
|
ROI |
8 regions |
|
|
OSD |
5regions;16*16/32*32/48*48/64*64/96*96 |
|
|
Picture Overlay |
1 region |
|
|
Privacy Mask |
4 regions |
|
|
Defog |
Yes |
|
|
Feature |
||
|
Alarm Trigger |
Motion Detection;Mask Alarm;Voltage Alarm;Disk Full;Disk R/W Error;IP Address Conflict;MAC Address Conflict;FTP Server Exception ;Event Input, Event Output |
|
|
Linkage Method |
send email;trigger sound;trigger recording;trigger capture;notify surveillance center |
|
|
Video Analytics |
Human/VehicleClassification;Tripwire;Double Tripwire;Perimeter;Object Abandon;Object Lost;Heatmap;Loitering;Running;Parking;People Counting;Crowed;Safety Helmet Detection;On Duty Detection;Video Abnormal;Audio Abnormal |
|
|
Rules of behavior analyse in 1 scene |
8 |
|
|
Early Warning(EW) |
N/A |
|
|
Auto-Tracking |
N/A |
|
|
Face Mode |
N/A |
|
|
Face Detection Performance |
N/A |
|
|
Network |
||
|
ANR |
ANR |
|
|
Protocols |
HTTP;HTTPS;TCP/IP;UDP;UPnP;ICMP;IGMP;SNMP;DHCP;DNS;DDNS;Easy DDNS;NTP;SMTP;SSL;802.1X;QoS;IPv4;IPv6;PPPOE;SSH;Unicast;Multicast;RTCP;ARP;SRTP;RTSP;FTP;SFTP;NAS |
|
|
System Compatibility |
onvif Profile S/T/G/M;CGI;MIL STONE;RTMP |
|
|
Remote Connection |
≤2 |
|
|
Client |
Easy7 Smart Client |
|
|
Moblie Client |
EasyLive Plus |
|
|
Web |
IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+ |
|
|
Interface |
||
|
Communication Interface |
1 RJ45 10M/ 100M self adaptive Ethernet port |
|
|
Audio I/O |
1channel in;1channel out |
|
|
Alarm I/O |
2channel in,3mA,3.3VDC;1channel out,1A,24VDC |
|
|
Built-In Mic |
Yes |
|
|
Built-In Speaker |
N/A |
|
|
Reset Button |
Yes |
|
|
On-board storage |
Built-in Micro SD card slot, up to 512 GB |
|
|
Additional interfaces |
1 channel RS-485 |
|
|
General |
||
|
Operating Temperature |
-35℃-65℃ |
|
|
Operating Humidity |
0-95% |
|
|
Storage Temperature |
-35℃-65℃ |
|
|
Storage Humidity |
0-95%(non-condensing) |
|
|
Power Supply |
DC12V±25%,MAX 9.5W;POE 802.3at,MAX 10.5W |
|
|
Protection |
Surge protection 2000V;Lightning proof 6000V;IP67 |
|
|
Boundary Dimensions |
265(L)105(W)105(H)mm |
|
|
Package Dimensions |
360(L)150(W)170(H)mm |
|
|
Gross Weight |
1.6kg |
|
|
Net Weight |
1.15kg |
|
Sorena SR-8458C
